TELEC certification for Bluetooth devices——ZRLK

Bluetooth products are very common in our lives, such as Bluetooth headsets and Bluetooth speakers. However, generally such wireless products need to apply for TELEC certification if they want to enter the Japanese market.

Introduction to Japan TELEC certification

TELEC certification is also called MIC certification. TELEC (Telecom Engineering Center) is the main registered certification body for conformity certification of radio equipment in Japan, MIC (Ministry of Internal Affairs and Communications) is the government agency that regulates radio frequency equipment in Japan, and MIC is the Ministry of Internal Affairs and Communications of Japan, which is responsible for compiling regulations and standards. TELEC is only one of the designated issuing agencies for MIC, so it is called TELEC certification or MIC certification. TELEC certification is mandatory, and the certification body is a registered certification body recognized by MIC in the scope of designated radio equipment.

Bluetooth device TELEC certification test project

1. Frequency Error Measurement (Frequency Error Measurement)

2. Coupling bandwidth/carrier frequency bandwidth test (Occupied Bandwidth and Spread-spectrum Bandwidth / Factor)

3. Unwanted Emission Intensity Measurement (Unwanted Emission Intensity Measurement)

4. Antenna Power Error Measurement (Antenna Power Error Measurement)

5. Receiver spurious disturbance test (Limitation of Collateral Emission of Receiver Measurement)

6. EIRP antenna power test (Transmission Antenna Gain (EIRP Antenna Power) Measurement)

7. 3dB lobe bandwidth test (Transmission Radiation Angle Width (3dB Beamwidth) Measurement)

8. Duty Cycle Measurement

9. Retention time test (retention time)

Information to be prepared for Bluetooth device TELEC certification application

1. Technical model specification table

2. Quality management system statement

3. Quality control confirmation method or manufacturer’s ISO 9001 certificate

4. Confirmation of construction guarantee

5. Rated power declaration

6. Antenna report

7. Test report including test results, test setup photos and inspections performed)

8. Block diagram, schematic diagram, material list, parts placement, IC data sheet, internal and external photos, product description, user manual, operation/technical description, accessory description)

9. Label information (label location, label content)

10. If you are an agent or authorized representative of the manufacturer, you need a letter/authorization letter

Bluetooth device TELEC certification process

1. Fill in the application form, prepare materials and samples

2. The testing agency reviews the data and preliminarily test the samples

3. The testing agency shall formally apply to the agency approved by the MIC of the Ministry of General Affairs

4. Institutional review documents

5. Sample test, provide test report (can be tested by authorized laboratory)

6. After the documents and test reports are passed, the Japanese MIC will issue a certificate.

For Bluetooth device TELEC certification, please contact our company ZRLK. We will provide you with professional and efficient testing and certification services with favorable prices and courteous service. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
