Bluetooth 2.4G product TELEC certification test processing——ZRLK

TELEC (MIC) certification includes Test Certification and Type Certification. Test certification is to verify each equipment unit, and the certification is only valid for each verified equipment unit; type certification refers to the verification of samples of a batch of equipment of the same design and manufacture, and the certification is valid for the batch of equipment. Valid, but if the design or manufacture of the device has changed, the device will need to be recertified. It is worth noting that the use of non-low power radio stations and their terminal equipment requires a license from the MIC. In addition, there are two cases for the compliance certification of telecommunications terminal equipment: for ordinary telephone devices, only JATE certification is required in accordance with the requirements of the Telecommunications Business Law; for wireless terminal equipment, in addition to JATE certification according to the requirements of the Telecommunications Business Law, it is also required TELEC certification as required by the Radio Law.

What is TELEC certification?

Japan's "Radio Law" requires type approval (ie, technical regulation compliance certification) for designated radio equipment. TELEC certification is mandatory. The certification body is a registered certification body recognized by MIC in the scope of designated radio equipment. TELEC (Telecom Engineering Center) is the main registered certification body for the conformity certification of radio equipment in Japan. TELEC is also called MIC certification in Japan. TELEC is MIC is one of the designated issuing agencies, so it is collectively referred to as TELEC certification.

Introduction to TELEC Certification Standards

The technical standards for TELEC certification refer to the classification and technical standards for designated radio equipment listed in the Technical Regulations Compliance Certification System above. It is worth noting that in the event of discrepancies between these technical standards and the technical requirements of the Radio Regulatory Commission Rules No. 18, the Radio Regulations shall prevail.

Bluetooth 2.4G product TELEC certification test project

The specific standard for 2.4GHz Bluetooth products is MIC No.88 Annex 43. The following specific test items that should be considered according to the standard are listed as follows:

1. Frequency Error Measurement;

2. Occupied Bandwidth and Spread-spectrum Bandwidth / Factor;

3. Unwanted Emission Intensity Measurement;

4. Antenna Power Error Measurement;

5. Receiver spurious disturbance test (Limitation of Collateral Emission of Receiver Measurement);

6. EIRP antenna power test (TransmissionAntenna Gain (EIRP Antenna Power) Measurement);

7. 3dB lobe bandwidth test (TransmissionRadiation Angle Width 3dB Bandwidth Measurement);

8. Duty Cycle Measurement;

9. Retentiontime test (retentiontime);

10. Interference Prevention and Carrier Sense (RadioInterference Prevention Capability & Carrier Sense Capability Measurement).

Bluetooth 2.4G product TELEC test process

1. to submit an application;

2. Sign the quotation and fill in the certification application form;

3. Provide samples and provide technical information, and pay the first payment;

4. The laboratory starts the test after receiving the sample;

5. After the test is OK, issue a report;

6. Submit the report to the TELEC agency to apply for the TELEC certificate;

7. The customer pays the balance;

8. TELEC certificate (also called MIC certificate) will be issued after the case is over.

Bluetooth 2.4G product TELEC certification fee

The cost of TELEC certification varies according to different products and functions. For example, the product has Bluetooth, WIFI function, and 2.4GHz function. The function is different and the cost is different. Even the Bluetooth single-mode and dual-mode are different, and the cost is also different. The specific TELEC certification fee needs to be quoted by the engineer after evaluation.

For Bluetooth 2.4G product TELEC certification, you can contact our company ZRLK, we will provide you with professional and efficient testing and certification services with favorable prices and thoughtful service. If you provide us with product pictures and specifications, we will give you corresponding cycles, quotations and specific solutions according to your products. You are welcome to inquire!
